Dao hợp kim phay ren CMTéc

Sắp xếp theo:

grid
list

Dao phay ren hợp kim CMTec MSHIDA1-MSHIDA2-MSHIDA3, Dao phay ren CMTéc MSHIDA1-MSHIDA2-MSHIDA3

Liên hệ

Mã sản phẩm: MSHIDA1-MSHIDA2-MSHIDA3

Thread Pitch d1 d2 L D Chamfer Teeth Flute Coated M0.8 0.20 0.60 2.4 50 4 0.1 1 1 MSHIDA100604-020A M0.9 0.225 0.66 2.7 50 4 0.12 1 1 MSHIDA100604-022A M1.0 0.25 0.73 3.0 50 4 0.15 1 1 MSHIDA100704-025A M1.2 0.25 0.92 3.6 50 4 0.15 1 1 MSHIDA100904-025A M1.4 0.30 1.05 4.2 50 4 0.19 1 1 MSHIDA101004-030A M1.6 0.35 1.21 4.8 50 4 0.22 1 1 MSHIDA101204-035A M2.0 0.40 1.55 6.0 50 4 0.25 1 2 MSHIDA201504-040A M2.5 0.45 2.00 7.5 50 4 0.29 1 2 MSHIDA202004-045A M3.0 0.50 2.44 9.0 60 6 0.33 1 2 MSHIDA202406-050A M4.0 0.70 3.20 12.0 60 6 0.45 1 2 MSHIDA203206-070A M5.0 0.80 4.00 15.0 60 6 0.53 1 2 MSHIDA204006-080A M6.0 1.00 4.85 18.0 75 6 0.65 2 3 MSHIDA304806-100A M8.0 1.25 6.50 24.0 75 8 0.8 2 3 MSHIDA306508-125A M10.0 1.50 7.90 30.0 75 8 1 2 3 MSHIDA307908-150A
Dao phay ren hợp kim CMTec MSHIA1-MSHIA2-MSHIA3, Dao phay ren CMTéc MSHIA1-MSHIA2-MSHIA3

Liên hệ

Mã sản phẩm: MSHIA1-MSHIA2-MSHIA3

Thread Pitch d1 d2 L D Chamfer Teeth Flute Coated M0.8 0.20 0.60 2.4 50 4 0.1 1 1 MSHIA100604-020 M0.9 0.225 0.66 2.7 50 4 0.12 1 1 MSHIA100604-022 M1.0 0.25 0.73 3.0 50 4 0.15 1 1 MSHIA100704-025 M1.2 0.25 0.92 3.6 50 4 0.15 1 1 MSHIA100904-025 M1.4 0.30 1.05 4.2 50 4 0.19 1 1 MSHIA101004-030 M1.6 0.35 1.21 4.8 50 4 0.22 1 1 MSHIA101204-035 M2.0 0.40 1.55 6.0 50 4 0.25 1 2 MSHIA201504-040 M2.5 0.45 2.00 7.5 50 4 0.29 1 2 MSHIA202004-045 M3.0 0.50 2.44 9.0 60 6 0.33 1 2 MSHIA202406-050 M4.0 0.70 3.20 12.0 60 6 0.45 1 2 MSHIA203206-070 M5.0 0.80 4.00 15.0 60 6 0.53 1 2 MSHIA204006-080 M6.0 1.00 4.85 18.0 75 6 0.65 2 3 MSHIA304806-100 M8.0 1.25 6.50 24.0 75 8 0.8 2 3 MSHIA306508-125 M10.0 1.50 7.90 30.0 75 8 1 2 3 MSHIA307908-150
Dao phay ren hợp kim CMTec CTHIU, Dao phay ren CMTéc CTHIU

Liên hệ

Mã sản phẩm: CTHIU

d1 L1 L D h Tpi UNC UNF UNEF Teeth Flute Coated 3 8.5 50 4 0.41 36 No.8 12 3 CTHIU303004-360A 3.3 11.1 50 4 0.46 32 No.10 No.12-3/8" 14 3 CTHIU303304-320A 3.8 11.8 50 4 0.52 28 No.12，1/4" 7/16"，1/2" 13 3 CTHIU303804-280A 4.6 12.7 60 6 0.52 28 1/4" 7/16"，1/2" 14 3 CTHIU304606-280A 9.2 22.7 75 10 0.52 28 7/16"，1/2" 25 4 CTHIU409210-280A 2.9 10.6 50 4 0.61 24 No.10 5/16"，3/8" 9/16"-11/16" 10 3 CTHIU302904-240A 3.5 11.6 50 4 0.61 24 No.12 5/16"，3/8" 9/16"-11/16" 11 3 CTHIU303504-240A 5.7 15.9 60 6 0.61 24 5/16"，3/8" 9/16"-11/16" 15 3 CTHIU305706-240A 7.4 19.1 60 8 0.61 24 3/8" 9/16"-11/16" 18 3 CTHIU307408-240A 11.9 28.6 100 12 0.61 24 9/16"-11/16" 27 4 CTHIU411912-240A 3.9 12.7 50 4 0.73 20 1/4" 7/16"，1/2" 3/4"-1" 10 3 CTHIU303904-200A 8.5 22.9 75 10 0.73 20 7/16"，1/2" 3/4"-1" 18 4 CTHIU408510-200A 9.9 25.4 75 10 0.73 20 1/2" 3/4"-1" 20 4 CTHIU409910-200A 15.9 38.1 100 16 0.73 20 3/4"-1" 30 5 CTHIU515916-200A 5.2 16.9 60 6 0.81 18 5/16" 9/16"，5/8" 11/16"-1 11/16" 12 3 CTHIU305206-180A 11.3 29.6 100 12 0.81 18 9/16"，5/8" 11/16"-1 11/16" 21 4 CTHIU411312-180A 11.9 32.5 100 12 0.81 18 5/8" 11/16"-1 11/16" 23 4 CTHIU411912-180A 6.7 19.1 60 8 0.92 16 3/8" 3/4" 12 3 CTHIU306708-160A 15.9 38.1 100 16 0.92 16 3/4" 24 4 CTHIU415916-160A 7.6 23.6 60 8 1.05 14 7/16" 7/8" 13 4 CTHIU407608-140A 18.7 44.4 100 20 1.05 14 7/8" 24 4 CTHIU418720-140A 8.9 25.4 75 10 1.13 13 1/2" 13 4 CTHIU408910-130A 10.3 29.6 100 12 1.22 12 9/16" 1"-1 1/2" 14 4 CTHIU410312-120A 19.9 50.8 100 20 1.22 12 1"-1 1/2" 24 5 CTHIU519920-120A 11 32.3 100 12 1.33 11 5/8" 14 4 CTHIU411012-110A 13.5 38.1 100 16 1.47 10 3/4" 15 5 CTHIU513516-100A 15.2 45.2 100 16 1.63 9 7/8" 16 4 CTHIU415216-090A 17 50.8 100 20 1.83 8 1" 16 4 CTHIU417020-080A
Dao phay ren hợp kim CMTec CTHI, Dao phay ren CMTéc CTHI

Liên hệ

Mã sản phẩm: CTHI

d1 L1 L D h Pitch M Mx1 Teeth Flute Coated 2.2 6 50 4 0.29 0.5 M3 M3.5~M16 12 3 CTHI302204-050A 3 8 50 4 0.29 0.5 M4 16 3 CTHI303004-050A 3.9 10 50 4 0.29 0.5 M5 20 3 CTHI303904-050A 2.8 8.4 50 4 0.4 0.7 M4 12 3 CTHI302804-070A 3.9 12 50 4 0.43 0.75 M6 16 3 CTHI303904-075A 3.5 10.4 50 4 0.46 0.8 M5 13 3 CTHI303504-080A 3.9 12 50 4 0.58 1 M6 M8~M40 12 3 CTHI303904-100A 5.9 16 60 6 0.58 1 M8 16 3 CTHI305906-100A 7.9 20 60 8 0.58 1 M10 20 3 CTHI307908-100A 9.9 24 75 10 0.58 1 M12 24 4 CTHI409910-100A 5.8 16.25 60 6 0.72 1.25 M8 13 3 CTHI305806-125A 7.7 20 60 8 0.72 1.25 M10 16 3 CTHI307708-125A 7.7 21 60 8 0.87 1.5 M10 M12~M48 14 3 CTHI307708-150A 9.4 24 75 10 0.87 1.5 M12 16 4 CTHI409410-150A 11.2 28.5 100 12 0.87 1.5 M14 19 4 CTHI411212-150A 11.9 33 100 12 0.87 1.5 M16 22 4 CTHI411912-150A 8.7 24.5 75 10 1.01 1.75 M12 14 4 CTHI408710-175A 9.9 28 75 10 1.15 2 M14 M17~M80 14 4 CTHI409910-200A 11.9 32 100 12 1.15 2 M16 M17~M80 16 4 CTHI411912-200A 13.9 40 100 16 1.44 2.5 M18~M22 16 5 CTHI513916-250A 15.9 42 100 16 1.73 3 M24 14 4 CTHI415916-300A
Dao phay ren hợp kim CMTec CTSIU, Dao phay ren CMTéc CTSIU

Liên hệ

Mã sản phẩm: CTSIU

d1 L1 L D h Tpi Thread Teeth Flute Coated 3 6.3 50 4 0.41 36 No.8 9 3 CTSIU303004-360A 3 6.3 50 4 0.46 32 No.8 8 3 CTSIU303004-320A 5.9 14.3 60 6 0.46 32 5/16" 18 3 CTSIU305906-320A 3.6 8.2 50 4 0.52 28 No.12 9 3 CTSIU303604-280A 7.9 19.9 60 8 0.52 28 7/16" 22 3 CTSIU307908-280A 4 8.5 60 6 0.61 24 No.12 8 3 CTSIU304006-240A 4 10.2 60 6 0.73 20 1/4" 8 3 CTSIU304006-200A 9.9 22.9 75 10 0.73 20 9/16" 18 5 CTSIU509910-200A 5 12.7 60 6 0.81 18 5/16" 9 3 CTSIU305006-180A 9.9 24 75 10 0.81 18 9/16" 17 5 CTSIU509910-180A 5.9 14.3 60 6 0.92 16 3/8" 9 3 CTSIU305906-160A 11.9 28.6 100 12 0.92 16 3/4" 18 5 CTSIU511912-160A 7.9 18.1 60 8 1.05 14 7/16" 10 3 CTSIU307908-140A 7.9 19.5 60 8 1.13 13 1/2" 10 3 CTSIU307908-130A 9.9 23.3 75 10 1.22 12 9/16" 11 5 CTSIU509910-120A 11.9 29.6 100 12 1.22 12 1" 14 5 CTSIU511912-120A 9.9 23.1 75 10 1.33 11 5/8" 10 5 CTSIU509910-110A 11.9 27.9 100 12 1.47 10 3/4" 11 5 CTSIU511912-100A 15.9 33.3 100 16 1.63 9 7/8" 12 5 CTSIU515916-090A 15.9 38.1 100 16 1.83 8 1" 12 5 CTSIU515916-080A 15.9 36.3 100 16 2.09 7 1 1/8" 10 5 CTSIU515916-070A 19.9 38.1 100 20 2.44 6 1 3/8" 9 5 CTSIU519920-060A 19.9 40.6 100 20 2.93 5 1 3/4" 8 5 CTSIU519920-050A 19.9 39.5 100 20 3.26 4.5 2" 7 5 CTSIU519920-045A
Dao phay ren hợp kim CMTec CSHI2, Dao phay ren CMTéc CSHI2

Liên hệ

Mã sản phẩm: CSHI2

d1 d2 L1 L2 Nd NL L D h Pitch Thread Teeth Flute Coated 5.0 4.85 1.0 13.7 6.6 9.5 60 8 0.58 1 M6 11 2 CSHI205008-100A 6.8 6.45 1.3 17.1 9 16.8 75 10 0.72 1.25 M8 11 2 CSHI206810-125A 8.5 8.08 1.5 22.1 11 11.6 80 12 0.87 1.5 M10 12 2 CSHI208512-150A 10.3 9.74 1.5 25.5 13.5 17.9 90 14 1.01 1.75 M12 12 2 CSHI210314-175A
Dao phay ren hợp kim CMTec CTSEU, Dao phay ren CMTéc CTSEU

Liên hệ

Mã sản phẩm: CTSEU

d1 L1 L D h Pitch Thread Teeth Flute Coated 5.9 14.3 60 6 0.49 32 No.6 18 3 CTSEU305906-320A 7.9 19.9 60 8 0.56 28 No.12 22 3 CTSEU307908-280A 9.9 22.9 75 10 0.78 20 1/4" 18 5 CTSEU509910-200A 9.9 24 75 10 0.87 18 5/16" 17 5 CTSEU509910-180A 11.9 28.6 100 12 0.97 16 3/8" 18 5 CTSEU511912-160A 11.9 29.6 100 12 1.3 12 9/16" 14 5 CTSEU511912-120A 15.9 38.1 100 16 1.95 8 1" 12 5 CTSEU515916-080A 19.9 38.1 100 20 2.6 6 1 3/8" 9 5 CTSEU519920-060A
Dao phay ren hợp kim CMTec CTSI, Dao phay ren CMTéc CTSI

Liên hệ

Mã sản phẩm: CSHI2

d1 L1 L D h Pitch Thread Teeth Flute Coated 3 6.7 50 4 0.43 0.75 M4.5 9 3 CTSI303004-075A 5.9 15 60 6 0.43 0.75 M8 20 3 CTSI305906-075A 3.6 8 50 4 0.46 0.8 M5 10 3 CTSI303604-080A 4 9 60 6 0.58 1 M6 9 3 CTSI304006-100A 7.9 20 60 8 0.58 1 M12 20 3 CTSI307908-100A 5 12.5 60 6 0.72 1.25 M8 10 3 CTSI305006-125A 5.9 15 60 6 0.87 1.5 M10 10 3 CTSI305906-150A 9.9 24 75 10 0.87 1.5 M14 16 5 CTSI509910-150A 11.9 30 100 12 0.87 1.5 M18 20 5 CTSI511912-150A 7.9 19.2 60 8 1.01 1.75 M12 11 3 CTSI307908-175A 9.9 24 75 10 1.15 2 M16 12 5 CTSI509910-200A 11.9 30 100 12 1.15 2 M18 15 5 CTSI511912-200A 11.9 30 100 12 1.44 2.5 M20 12 5 CTSI511912-250A 15.9 36 100 16 1.73 3 M24 12 5 CTSI515916-300A 15.9 38.5 100 16 2.02 3.5 M30 11 5 CTSI515916-350A 15.9 40 100 16 2.31 4 M36 10 5 CTSI515916-400A 19.9 40 100 20 2.89 5 M48 8 5 CTSI519920-500A 19.9 36 100 20 3.46 6 M64 6 5 CTSI519920-600A
